Brand: Uniview Model: XVR301-08F Type: XVR Video/Audio Analog Video Input: 8-ch, BNC Video Live: 1080P Video Recording: 720P IP Video Input: 2-ch (only IP up to 10ch), Each Channel up To 6MP Video Inputs: AHD/CVI/TVI/CVBS Frame Rate: Main stream: 1080P Lite@15fps / 720P@15fps – Sub stream: D1@12fps / D1@15fps VGA/HDMI Output: 1920x1080p/60Hz, 1920x1080p/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz Decoding Capability: Analog: 8 x 1080P Lite @15, 8 x 720P @15 – IP: 1 x 6MP@20, 2 x 1080P@30 Interface HDD Type: 1x SATA Interface Capacity: Up To 6TB For Each HDD Network Interface: 1x RJ45 10M/100M Self-Adaptive Ethernet Interface USB Interface: Rear Panel: 2 x USB2.0 Network Incoming Bandwidth: 24Mbps (Up to 40Mbps after all analog channel conversion) Outgoing Bandwidth: 64Mbps Remote Users: 128 Protocols: TCP/IP, P2P, UPnP, NTP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP General General Alarm: Motion Detection Operating Condition: Temperature: -10°C ~ 55°C ( 14°F ~ 131°F) / Humidity: ≤ 90% RH(non-condensing) Power Supply: 12V DC Power Consumption: ≤ 10 W( without HDD ) Dimensions: 190 × 202 × 42 mm Warranty: 1 Year Show More Show Less
